Minimal tid - maksimal innovasjon
Fujitsus avanserte CELSIUS -arbeidsstasjon gir maksimal ytelse og sikkerhet. Alle produktene er designet for å kunne bruke en rekke ledende applikasjoner som Autodesk, Adobe Premiere, Siemens PLM eller PTC.
Utviklere kan nå prioritere tiden sin til det som er mest verdifullt for dem: innovasjon.
Opplev fantastisk arbeidsstasjonsytelse kombinert med elegant design.
Det er ingen kompromisser om tilkobling, enten du er borte, i et møte eller på kontoret ditt
Datasikkerhet gir trygghet.
Arkitekter, ingeniører og designere kan nå vise frem arbeidet sitt i sanntid med fascinerende VR -teknologi.
| NVIDIA QUADRO RTX 5000 | |
|---|---|
| GPU Memory | 16 GB GDDR6 |
| Memory Interface | 256-bit |
| Memory Bandwidth | Up to 448 GB/s |
| ECC | Yes |
| NVIDIA CUDA Cores | 3,072 |
| NVIDIA Tensor Cores | 384 |
| NVIDIA RT Cores | 48 |
| Single-Precision Performance | 11.2 TFLOPS |
| Tensor Performance | 89.2 TFLOPS |
| NVIDIA NVLink | Connects 2 Quadro RTX 5000 GPUs1 |
| NVIDIA NVLink bandwidth | 50 GB/s (bidirectional) |
| System Interface | PCI Express 3.0 x 16 |
| Power Consumption | Total board power: 265 W Total graphics power: 230 W |
| Thermal Solution | Active |
| Form Factor | 4.4” H x 10.5” L, Dual Slot, Full Height |
| Display Connectors | 4xDP 1.4, 1x USB-C |
| Max Simultaneous Displays | 4x 4096x2160 @ 120 Hz, 4x 5120x2880 @ 60 Hz, 2x 7680x4320 @ 60 Hz |
| Encode / Decode Engines | 1X Encode, 2X Decode |
| VR Ready | Graphics APIs |
| Graphics APIs | DirectX 12.07 Shader Model 5.17, OpenGL 4.68, Vulkan 1.18 |
| Compute APIs | CUDA, DirectCompute, OpenCL™ |
| NVIDIA QUADRO RTX 4000 | |
|---|---|
| GPU Memory | 8 GB GDDR6 |
| Memory Interface | 256-bit |
| Memory Bandwidth | Up to 416GB/s |
| NVIDIA CUDA Cores | 32304 |
| NVIDIA Tensor Cores | 288 |
| NVIDIA RT Cores | 36 |
| Single-Precision Performance | 7.1 TFLOPS |
| Tensor Performance | 57 TFLOPS |
| System Interface | PCI Express 3.0 x 16 |
| Power Consumption | Total board power: 160W Total graphics power: 125W |
| Thermal Solution | Active |
| Form Factor | 4.4” H x 9.5” L, Single Slot |
| Display Connectors | 3xDP 1.4, 1x USB-C |
| Max Simultaneous Displays | 4x 3840x2160 @ 120 Hz 4x 5120x2880 @ 60 Hz 2x 7680x4320 @ 60 Hz |
| VR Ready | Yes |
| Graphics APIs | Shader Model 5.15, OpenGL 4.6, DirectX 12.0, Vulkan 1.16 |
| Compute APIs | CUDA, DirectCompute, OpenCL™ |
| NVIDIA QUADRO P2200 | |
|---|---|
| GPU Memory | 5 GB GDDR5X |
| Memory Interface | 160-bit |
| Memory Bandwidth | Up to 200 GB/s |
| NVIDIA CUDA Cores | 1280 |
| System Interface | PCI Express 3.0 x 16 |
| Power Consumption | 75W |
| Thermal Solution | Active |
| Form Factor | 4.4” H x 7.9” L, Single Slot |
| Display Connectors | 4x DP 1.4 |
| Max Simultaneous Displays | 4 direct, 4 DP 1.4 Multi-Stream |
| Display Resolution | 4x 4096x2160 @ 120Hz 4x 5120x2880 @ 60Hz |
| Graphics APIs | Shader Model 5.1, OpenGL 4.6, DirectX 12.0, Vulkan 1.1 |
| Compute APIs | CUDA, DirectCompute, OpenCL™ |
| NVIDIA QUADRO P1000 | |
|---|---|
| GPU Memory | 4 GB GDDR5 |
| Memory Interface | 128-bit |
| Memory Bandwidth | Up to 82 GB/s |
| NVIDIA CUDA® Cores | 640 |
| System Interface | PCI Express 3.0 x 16 |
| Max Power Consumption | 47W |
| Thermal Solution | Active |
| Form Factor | 2.713” H x 5.7” L, Single Slot, Low Profile |
| Display Connectors | 4x mDP 1.4 |
| Max Simultaneous Displays | 4 direct, 4 DP 1.4 Multi-Stream |
| Display Resolution | 4x 4096x2160 @ 60Hz 4x 5120x2880 @ 60Hz |
| Graphics APIs | Shader Model 5.1, OpenGL 4.5, DirectX 12.0, Vulkan 1.0 |
| Compute APIs | CUDA, DirectCompute, OpenCL™ |
| NVIDIA QUADRO P400 | |
|---|---|
| GPU Memory | 2 GB GDDR5X |
| Memory Interface | 64-bit |
| Memory Bandwidth | Up to 32 GB/s |
| NVIDIA CUDA® Cores | 256 |
| System Interface | PCI Express 3.0 x 16 |
| Power Consumption | 30W |
| Thermal Solution | Active |
| Form Factor | 2.713” H x 5.7” L, Single Slot, Low Profile |
| Display Connectors | 3x mDP 1.4 |
| Max Simultaneous Displays | 3 direct, 3 DP 1.4 Multi-Stream |
| Display Resolution | 3x 4096x2160 @ 60Hz 1x 5120x2880 @ 60Hz |
| Graphics APIs | Shader Model 5.1, OpenGL 4.5, DirectX 12.0, Vulkan 1.0 |
| Compute APIs | CUDA, DirectCompute, OpenCL™ |
| NVIDIA QUADRO RTX 8000 | |
|---|---|
| GPU Memory | 48 GB GDDR6 |
| Memory Interface | 384-bit |
| Memory Bandwidth | 672 GB/s |
| ECC | Yes |
| NVIDIA CUDA Cores | 4,608 |
| NVIDIA Tensor Cores | 576 |
| NVIDIA RT Cores | 72 |
| Single-Precision Performance | 16.3 TFLOPS |
| Tensor Performance | 130.5 TFLOPS |
| NVIDIA NVLink | Connects 2 Quadro RTX 8000 GPUs |
| NVIDIA NVLink bandwidth | 100 GB/s (bidirectional) |
| System Interface | PCI Express 3.0 x 16 |
| Power Consumption | Total board power: 295 W Total graphics power: 260 W |
| Thermal Solution | Active |
| Form Factor | 4.4” H x 10.5” L, Dual Slot, Full Height |
| Display Connectors | 4xDP 1.4, VirtualLink (1) |
| Max Simultaneous Displays | 4x 3840 x 2160 @ 120 Hz, 4x 5120x2880 @ 60 Hz, 2x 7680x4320 @ 60 Hz |
| Encode / Decode Engines | 1X Encode, 1X Decode |
| VR Ready | Yes |
| Graphics APIs | DirectX 12.0, Shader Model 5.1, OpenGL 4.6, Vulkan 1.1 |
| Compute APIs | CUDA, DirectCompute, OpenCL™ |
VR kan fremkalde en oplevelse, der ikke kan måles med at se en 3D CAD-model, realistiske gengivelser eller animation på en 2D-skærm.
Der gås ikke på kompromis, når det kommer til professionel Virtual Reality:
Nyd en fuldstændig fordybende oplevelse i VR med Fujitsu og Nvidia.
